ICES622X

COM Express Type 6, COMPACT Size Module with Intel® Atom™ X6000 Family Processor DDR4/GbE/2SATA/6 X PCIe and DP/USB3.2

主要特点
  • Intel® Atom™ Processors, X6000 Series Family support
  • Dual channel DDR4 SO-DIMM memory up to 3200MT/s, IBECC/non ECC, max. 32GB
  • Support 4 x PCIex1, 2 x USB3.2/8 x USB2.0/2 x SATA3.0 and GbE
  • 2 x DP/VGA interfaces
  • Dimension 95 x 95mm (W x L)


Overview

The ICES 622 is a COM Express Type 6 compact size module that features Intel® Atom™ X6000 processor, and two DDR4 SO-DIMM memory socket without ECC support, up to 32GB 3200MHz. The ICES 622 integrates with Intel® Gen11 LP Graphic to support dual displays of VGA resolution up to 1920 x 1200 resolutions and 2DPs link with HDMI1.4a/DP1.2 configurations. The high performance ICES 622 COM Express module supports SATA, USB2.0 & USB3.2/VGA/DP (HDMI)/PCIex1.
